Features
- Klipper high-speed system
- 7-inch HD capacitive touchscreen
- Industrial-grade linear guides for XY axis
- Leadshine high-precision servo motors for XY axis (closed-loop drive)
- Dual Z-axis synchronized integrated leadscrews
- BMG dual gears
- 70W high-power heating rod, Volcano nozzle extruder for high-speed printing
- Internal temperatures up to 60℃, easily printing high-temperature materials like ABS and PLA.
Datasheet
| Model | 5060 |
| Printing Size | 500*500*600mm |
| Layer Resolution | 0.05-0.35mm (0.4 Nozzle) |
| Whether Having An Air Filtration System | Dual-fan Filtration System |
| Whether Supporting Filament Runout Pause Alarm | Yes
|
| Whether Supporting Wi-Fi File Transfer | Yes |
| Number of Nozzles | 1
|
| Print Head | Single Color Printing |
| Printing Speed | 30-350mm/s |
| Motion System | XY-axis Synchronous Belt Linear Guide, Dual Z-axis Integrated Synchronous LeadsCrew Motor |
| Forming Drive | Leadshine Closed-loop Servo Motor Group for XY-axis (42cme08 + CL1-507) |
| Chassis Structure | Fully Enclosed Constant Temperature Chassis (Double Door) |
| Filament Storage Box | Hanging Type |
| Lighting function |
|
| Extruder Diameter | 0.4/0.6/0.8/1.0mm |
| Extruder Working Temperature | 0-320℃ |
| Heating Platform | Independent Power Supply Silicone Heated Bed + 12mm Aluminum Plate + Detachable Magnetic Steel Plate |
| Display Characteristics | 7-Inch HDMI HD Capacitive Screen |
| Central Processing Unit (CPU) | 32-bit ARM CPU Microcontroller |
| Printing Methods | LAN (Wi-Fi) |
| Power Requirements | AC100v-AC240v 50Hz-60Hz |
| Supported File Formats | STL, OBJ |
| Operating System Support | Windows/Linux/MAC |
| Machine Surface Treatment | Sheet Metal with High-Temperature Baking Paint, Creating a Unique Appearance |
| Machine Dimensions | 670*720*1230mm |
| Packaging Dimensions | 780*730*1260mm |
| Gross Weight | ≥48kg |
| Packaging Specifications | High-Strength Packaging Box That Meets Export Standards |
Compatible Printing Materials:
Recommended PLA (eco-friendly, non-toxic), TPU, Carbon Fiber, ASA, ABS, PETG, Nylon and other standard 1.75mm diameter 3D printing materials
