TECHNICAL DATASHEET
PRODUCT DESCRIPTION
Aluminum Alloy is the most widely used class of non-ferrous metal structure materials in the industry. The models printed has low density but relatively high strength which is close to or beyond high-quality steel and good plastic.
TYPICAL FEATURES
> Build parts offers excellent mechanical properties,such as hardness and tensile strength
> Outstanding corrosion resistance
> Good thermal and electrical conductivity
> High dynamic toughness
TYPICAL BENEFITS
> Functional parts in automotive industries
> Light weight structural geometries for aerospace
> Thermal applications such as heat exchangers
> Robotics &Engineering
Technical Datasheet
General Properties | Density ISO3369 | ≥2.65 g/cm³ |
Mechanical Properties (As built) | Tensile Strength ISO6892-1 | ≥430 MPa |
Yield Strength ISO6892-1 | ≥250 MPa |
Elongation after Fracture ISO6892-1 | ≥5 % |
Vickers hardness ISO6507-1 | ≥120 HV5/15 |
Thermal conductivity at 20 ºC | 98W/mK-108W/mK |
Surface roughness Ra Z | 6-10μm |
Mechanical Properties (Heat treated) | Tensile Strength ISO6892-1 | ≥300 MPa |
Yield Strength ISO6892-1 | ≥200 MPa |
Elongation after Fracture ISO6892-1 | ≥10 % |
Vickers hardness ISO6507-1 | ≥70 HV5/15 |
Hardness (HRC) ISO6507-1 | ≥50 |
Thermal conductivity at 20 ºC | 163W/mK-183W/mK |
