| BASIC INFORMATION |
| Max Printing Size | 1000*1000*600mm |
| Machine Size | 160cm(W)*170cm(L)*243cm(H) |
| Rated Power Consumption | 1.8KVA |
| Machine Weight | 1630kg |
| LASER SYSTEM |
|
| Laser Type | Solid-state frequency tripled Nd: YV04 |
| Wavelength | 355nm |
| Power | Resin Surface Power ≥ 300 mW |
| OPTICAL & SCANNING SYSTEM |
| Variable Beam System | Galvo/Closed-loop |
| Beam Size (diameter @1/e2) | 0.08-0.8mm(Variable Beam)
|
| Max Scanning Speed | 15.0m/s |
| RECOATING SYSTEM |
| Main Structure | Marble recoated frame, marble elevator holder, and marble scanning system base |
| Coating Mode | Intelligent position vacuum recoating |
| Vertical Resolution Ratio | 0.0005mm |
| Repeat Positioning Accuracy | ±0.01mm |
| Layer Thickness | 0.05mm~0.2mm |
| Accuracy | L≤100mm, ±0.1mm; L<100mm, ±0.1%*L |
| CONTROL SOFTWARE |
| Motion Control System | Closed-loop |
| Machine Control Software | KINGS 3D control software |
| Input Data File Format | STL/SLC |
| Operating System | Windows 10 |
| Network Type and Protocol | Ethernet, TCP/IP |
| INSTALLATION CONDITION |
| Electrical Requirement | 200-240VAC 50/60Hz, single-phase,10A |
| Ambient Temperature | 20-26ºC (72-79℉) |
| Relative Humidity | ＜40%，non-condensing |
| First Tank Resin | 850kg |
| WARRANTY |
| Machine | Two years |
| Laser | Two years |
If you would like to know more about this machine, please refer to the detailed datasheet below.
