Basic information
Construction Size: 1200*800*650mm
Equipment Size (without display): 198cm(W)×177cm(D)×230cm(H)
Machine Weight: 2900kg
Rated Dissipation: 2.2KVA
Product Details
BASIC INFORMATION | |
Max Printing Size | 1200*800*650mm |
Machine Size | 198cm(W)×177cm(D)×230cm(H) |
Rated Power Consumption | 2.2KVA |
Machine Weight | 2900kg |
LASER SYSTEM | |
Laser Type | Solid-state frequency tripled Nd: YV04 |
Wavelength | 355nm |
Power | Resin Surface Power≥ 300 mW |
OPTICAL & SCANNING SYSTEM | |
Scanning Mode | Germanic galvanometer scanner |
Variable Beam System | Galvo/Closed-loop |
Beam Size (diameter @1/e2) | 0.075-0.8mm (Variable Beam) |
Max Scanning Speed | 15.0m/s |
RECOATING SYSTEM | |
Main Sturcture | Marble recoater frame, marble elevator holder and marble scanning system base |
Coating Mode | Intelligent position vacuum recoating |
Vertical Resolution Ratio | 0.0005mm |
Repeat Positioning Accuracy | ±0.01mm |
Layer Thickness | 0.05mm~0.25mm |
Accuracy | L≤150mm, ±0.1mm; L>150mm, ±0.1%*L |
CONTROL SOFTWARE | |
Motion Control System | Closed-loop |
Machine Control Software | KINGS 3D control software |
Input Data File Format | STL/SLC |
Operating System | Windows 7/10 |
Network Type and Protocol | Ethernet,TCP/IP |
INSTALLATION CONDITION | |
Electrical Requirement | 200-240VAC 50/60Hz, single-phase,10A |
Ambient Temperature | 20-26ºC (72-79℉) |
Relative Humidity | <40%,non-condensing |
First Tank Resin | About 950kg |
WARRANTY | |
Machine | Two years |
Laser | Two years |
