Basic information:
Brand Name:Kings 3D Printing
Construction Size: 850mm(X)×850mm(Y)×500mm(Z)
Equipment Size (without display): 140cm(W)*149cm(D)*243cm(H)
Equipment Weight: 1900kg
Rated Dissipation: 1.8KVA
Product Details
1. Fast service: Within Mainland China, we respond and arrive at the customer company within 24 hours to solve the problem;
2. Supply Chain Advantages: Involved in 3D printers, 3D printing materials, 3D printing service industry chain;
3. Highly Professional: We collaborate with industry experts to provide customers with more accurate and effective solutions;
4. Multi-attribute Material: We have developed unique materials with different attributes for different industries to meet their specific requirements.
BASIC INFORMATION | |
Max Printing Size | 850*850*500mm |
Machine Size | 140cm(W)*149cm(D)*243cm(H) |
Rated Power Consumption | 1.8KVA |
Machine Weight | 1900kg |
LASER SYSTEM | |
Laser Type | Solid-state frequency tripled Nd: YV04 |
Wavelength | 355nm |
Power | Resin Surface Power≥ 300 mW |
OPTICAL & SCANNING SYSTEM | |
Scanning Mode | Germanic galvanometer scanner |
Variable Beam System | Galvo/Closed-loop |
Beam Size (diameter @1/e2) | 0.075-0.8mm(Variable Beam) |
Max Scanning Speed | 15.0m/s |
RECOATING SYSTEM | |
Main Sturcture | Marble recoater frame, marble elevator holder and marble scanning system base |
Coating Mode | Intelligent position vacuum recoating |
Vertical Resolution Ratio | 0.0005mm |
Repeat Positioning Accuracy | ±0.01mm |
Layer Thickness | 0.05mm~0.25mm |
Accuracy | L≤150mm, ±0.1mm; L>150mm, ±0.1%*L |
CONTROL SOFTWARE | |
Motion Control System | Closed-loop |
Machine Control Software | KINGS 3D control software |
Input Data File Format | STL/SLC |
Operating System | Windows 7/10 |
Network Type and Protocol | Ethernet,TCP/IP |
INSTALLATION CONDITION | |
Electrical Requirement | 200-240VAC 50/60Hz, single-phase,10A |
Ambient Temperature | 20-26ºC (72-79℉) |
Relative Humidity | <40%,non-condensing |
First Tank Resin | About 550kg |
WARRANTY | |
Machine | Two years |
Laser | Two years |
