Advantages & Features
1. Marble frame structure, high-grade screw guide rails, high-precision liquid level sensor, and precision CNC calibration plate for calibration.
2. Paired with self-developed photosensitive materials, matching the characteristics of the equipment and materials, we have developed the optimal process parameter package.
3. Utilizing a marble platform with dual guide rails and a dual belt structure, achieving a silent and ultra-smooth coating movement system; real-time laser detection of liquid level, combined with a vacuum suction scraper system, ensures printing stability.
4. Automatically identifies internal and external surface information of single-section parts, and instantly switches between large and small laser spots for scanning, significantly improving printing speed.
5. The laser path is enclosed for dust prevention, greatly extending the lifespan of optical components and improving environmental adaptability; online laser detection with automatic power attenuation compensation.
6. Standard lifting float controls the liquid level height quickly and accurately without the need for frequent refills; high-precision transmission with a servo motor and ball screw ensures the accuracy of part dimensions.
7. Self-developed Kings SLA control system with tiered control permissions, open process parameters, and shared company parameter package support printing with various photosensitive resin materials to meet diverse customer requirements.
8. Using a short-distance flat-field lens enhances scanning accuracy and further improves the dimensional accuracy of printed products.
Applications
Dental Models, Shoe Mold Manufacturing, Jewelry and Accessories, Automotive Parts, Medical Models and Instruments, Scientific Research and Education
Datasheet
Printing Size | 400mm(X)*400mm(Y)*200mm(Z)
|
Printing Precision
| ±0.08(L≦100mm); ±0.1%*L(L>100mm) |
Layer Thickness
| Optional between (0.05mm-0.2mm)
|
Laser Type
| Diode-Pumped Solid-State Laser Nd, Wavelength 355nm |
| Beam Size | Variable Beam Size between 0.08mm-0.8mm |
| Scanning System | High-speed Scanning Galvanometer System, Paired with F-theta Lens |
| Scanning Speed | 8-15m/s automatically generates scanning paths |
| Equipment Control Software | Kings SLA control software, independently developed, copyrighted |
Operating System
| Windows 10 |
| Data Interface | STL, SLC |
| Power Supply | 200-240V, 50/60Hz, Unidirectional 10A |
| Rated Power Consumption | 1.2 KVA |
Heating Method
| Hot Air Heating (optional) |
| Ambient Temperature | 20-26℃ |
| Equipment Dimensions | 85cm(W)*105cm(D)*190cm(H) |
| Relative Humidity | ≦40%, Frost-free |
| Equipment Weight | 650kg
|
| First Tank Weight | 70kg |
